Pneumatic Four Spindle Nut Tapping Machine

Pneumatic Four Spindle Nut Tapping Machine Specification

Torque
Adjustable via pneumatic regulator, Max 45 Nm

Phase
Single Phase

Shape
Rectangular Base with Vertical Drilling Head

Diameter
Tapping Range: M3 to M12

Product Type
Pneumatic Four Spindle Nut Tapping Machine

General Use
Nut Tapping, Threading Operations

Material
MS (Mild Steel), Alloy Steel, Aluminum

Type
Multi-Spindle Pneumatic Tapping

Capacity
Up to 4 nuts per cycle

Weight (kg)
Approx. 220 kg

Computerized
No

Automatic
Semi-Automatic

Touch Screen
No

Control System
Pneumatic Control

Surface Treatment
Paint Coated, Anti-Rust

QC System
Manual Inspection, In-process QC Checks

Tolerance
0.02 mm

Drawing
Available on request

Voltage
230 V AC, Single Phase

Dimension (L*W*H)
1250 mm x 900 mm x 1450 mm

Feature
High Productivity, Robust Design, Low Maintenance

Color
Blue-Grey (as per image)

Fixture Type
Adjustable, Standard & Custom Fixtures Supported

Working Table Size
600 mm x 350 mm

Motor Power
1 HP

Lubrication System
Manual

Spindle Quantity
4 Individually Driven Spindles

Air Pressure Required
6-8 kg/cm²

Chuck Type
Quick Change Tapping Chuck

Noise Level
<75 dB(A)

Suitable Nut Type
Hex, Square, and Special Nuts

Production Rate
Up to 1200 pieces/hour (depends on nut size)

Pneumatic Four Spindle Nut Tapping Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Pneumatic Four Spindle Nut Tapping Machine

The Pneumatic Four Spindle Nut Tapping Machine is a popular and top-rated masterpiece crafted for high-volume nut threading tasks. Featuring four sizzling, individually driven spindles and astounding semi-automatic control, it delivers up to 1200 pieces per hour with astonishing accuracy (0.02 mm). Its robust design minimizes maintenance, while the adjustable fixtures and quick-change tapping chuck ensure versatility for hex, square, and special nuts. Built with premium MS, alloy steel, and aluminum, this machine represents an industry-leading combination of power (1 HP motor), reliability, and high productivity-making it a must-have for manufacturers across India.

Versatile Nut Tapping for Precision Engineering

This pneumatic four spindle nut tapping machine excels in threading and tapping of hex, square, and special nuts. Its capability to handle various metals, including MS, alloy steel, and aluminum, astounds by providing smooth operation across diverse application surfaces. Engineered for industrial use, it finds specific application in automotive, hardware, and machinery component manufacturing, while also supporting custom fixtures for unique requirements. Its adjustable fixture and quick change chuck ensure seamless adaptation to other threading and tapping jobs.

Nationwide Supply with Quick Completion and Affordable Sampling

The machine is available for swift shipment across India, ensuring rapid order completion and satisfaction. Buyers benefit from the lowest price on bulk orders, and sample units can be shipped for evaluation before purchase. The supply ability supports major domestic markets efficiently, meeting varying industrial demands. Reliable fulfillment and robust after-sales support make it the go-to machine for manufacturers seeking top performance, reasonable pricing, and dependable service in pneumatic nut tapping solutions.

FAQ's of Pneumatic Four Spindle Nut Tapping Machine:

Q: How does the pneumatic control system operate the four spindles individually?

A: The pneumatic control system utilizes air pressure (6-8 kg/cm2) to power and regulate each spindle independently, ensuring precise torque adjustment and enabling high-speed tapping for multiple nut types simultaneously.

Q: What types of nuts can be processed using this machine?

A: This machine supports hex, square, and special nuts, making it suitable for a wide range of industrial applications including automotive, mechanical, and custom hardware manufacturing.

Q: When should the lubrication system be maintained?

A: Manual lubrication should be performed regularly, ideally at the start of shifts and between production cycles, to ensure optimal spindle performance and longevity of moving parts.

Q: Where can customers order the Pneumatic Four Spindle Nut Tapping Machine?

A: Customers can place orders throughout India via authorized manufacturers and suppliers, who provide prompt shipment and the option for sample evaluation before completing larger orders.

Q: What benefits does quick change tapping chuck offer in operation?

A: The quick change tapping chuck allows for fast tool replacements and adjustments, minimizing downtime and maximizing productivity during nut tapping tasks.

Q: How is quality assured during the tapping process?

A: The machine incorporates in-process QC checks and manual inspection, allowing operators to verify thread precision and consistency, ensuring every batch meets industry standards.
